PROJECT DELIVERABLES
Report on metrological methods for characterisation of resistors and capacitors for their stability, tracking and non-linear behaviour down to and below -120 dB THD and of electronic switches for their injection currents and transients’ stability, as well as results obtained on a selected set of high-grade resistors and capacitors.
Report on the assessment of at least 2 designs for novel amplifiers (composite operational amplifiers (COPAs)) for integrator and front-end digital circuitry with zero drift, extremely high gain, low noise and error below 1 ppm. This includes the development of the metrological tools to evaluate their performance and the results from this evaluation.
Report on the development of a precision (< 50 ps jitter) timing solution for the ADC architectures with a galvanically isolated external trigger, lock-in and internal clock frequency output. This includes the development of the metrological tools to evaluate its performance and a comprehensive report on the jitter and synchronisation performance achieved.
PRESENTATIONS
22RPT02 True8DIGIT - Towards a true 8-digit digitiser, EURAMET TC-EM, METAS, Oct 2023
Towards a true 8-digit digitiser – EU Project overview and progress", International Symposium: High Performance Digitizer and DC Metrology, Slovenia, Feb 2024
Measuring Wideband Nonlinearity of Analog to Digital Converters, IEEE I2MTC, Glasgow, Scotland, May 2024
Is a digitizer with sub-ppm accuracy feasible?, 2024 National Conference of Standards Laboratories International (NCSLI), Denver, Colorado, July 2024
Quadrature bridge for capacitor non-linearity measurement, 2024 Conference on Precision Electromagnetic Measurements (CPEM), Denver, Colorado, July 2024
Project Progress Presentation at EURAMET TC-EM SCs Joint Meetings at IPQ, Annual meetings of the three subcommittees of the EURAMET Technical Committee for Electricity and Magnetism — SC DC and Quantum Metrology, SC Low Frequency, SC Power and Energy, combined with an European Metrology Networks / Smart Electricity Grids meeting, Lisbon (Caparica), Portugal, June 2025
Digital Multimeters Sampling Performance Comparison, 2024 Conference on Precision Electromagnetic Measurements (CPEM), Denver, Colorado, July 2024
POSTERS
Quadrature bridge for capacitor non-linearity measurement, 2024 Conference on Precision Electromagnetic Measurements (CPEM), Denver, Colorado, July 2024 (pdf)
22RPT02 True8DIGIT project status, EURAMET TC-Electricity and Magnetism (TC-EM) Annual Meeting 2025, RISE, Borås (Sweden) (pdf)
Digital Multimeters Sampling Performance Comparison, 2024 Conference on Precision Electromagnetic Measurements (CPEM), Denver, Colorado, July 2024 (pdf)
STANDARDS & REGULATORY ACTIVITIES
IEEE TC10 - Presentation of consortium activities / research results, July 2023
IEC TC85 WG22 - The committee secretary has been informed of the project, Nov 2023
IEC TC47 SC47A - The committee secretary has been informed of the project, Nov 2023
